ASME SA249 ERW Bright Annealed Duplex Stainless Steel Welded Tube For Heat Exchanger

Minimum Order Quantity : negotiable Price : 2500-12000USD/TON
Packaging Details : Plywood Case / Bundles Delivery Time : 25 Days
Payment Terms : T / T ; L / C Supply Ability : 500 Tons / Month
Place of Origin: CHINA Brand Name: MTSCO
Certification: ISO 9001 & PED & AD2000 Model Number: MTSCOSSWT55

Detail Information

Material: Stainless Steel Surface: 320 # Or 400 # Outside Polished
Delivery Condition: Soft / Hard Type: Welded
Process Method: ERW , EFW Etc PMI Test: 100%
High Light:

welded stainless steel tubing

,

welding round tube

Product Description

ASME SA249 ERW Bright Annealed Duplex Steel Welded Tube For Heat Exchanger



1 . OD ( Outer Diameter ) : 3.18mm to 101.6mm
2 . WT ( Wall Thickness ) :  0.5mm to 20mm
3 . Length : According to customer's requirement
4 . Standards : ASTM A312; ASTM A269; ASTM A789; ASTM A790 etc
5 . Process Method : ERW, EFW etc





Industry & AdvantageApplicationa) Petroleum
b) Chemical industry
c) Instrument
d) Industrial transportation
e) Mechanical structure industry
f) Need high corrision ability pipe's industry, such as offshore industry etc
Advantagesa) Superior surface finish,
b) Better mechanical property
c) More precise dimension
d) Perfect inspection method and inspection equipment
Terms & ConditionsPrice ItemFOB, CFR, CIF or as negotiation
PaymentT/T, LC or as negotiation
Delivery Time30 working days after received your deposit (Normally according to the order quantity)
PackageIron case; woven bag or as per customer’s requirement
Quality RequirementMill Test Certificate will be supplied with shipment, Third Part Inspection is acceptable
QualityTestNTD(Ultrasonic test, Eddy Current test);
Mechanical Test(Tension Test, Flaring Test, Flattening Test, Hardness Test, Hydraulic test);
Metal Test(Metallographic Analysis, Impact Test-High/low temperature);
Chemical Analysis(Photoelectric Emission Spectroscopic)
MarketMain MarketEurope, Middle East, Southeast Asia, South America. etc




ASTM A249 Standard :


Size ODNominal WallOutside DiameterLengthWall
1/2" (12.7)0.065" (1.65)/0.049" (1.25)+/-0.005 (0.13)+1/8" (3.18) - 0+/-10.0%
3/4" (19.1)0.065" (1.65)/0.049" (1.25)+/-0.005 (0.13)+1/8" (3.18) - 0+/-10.0%
1" (25.4)0.065" (1.65)/0.049" (1.25)+/-0.005 (0.13)+1/8" (3.18) - 0+/-10.0%
1-1/2" (38.1)0.065" (1.65)/0.049" (1.25)+/-0.008" (0.20)+1/8" (3.18) - 0+/-10.0%
2" (50.8)0.065" (1.65)/0.049" (1.25)+/-0.008" (0.20)+1/8" (3.18) - 0+/-10.0%
2-1/2" (63.5)0.065" (1.65)+/-0.010" (0.25)+1/8" (3.18) - 0+/-10.0%
3" (76.2)0.065" (1.65)+/-0.010" (0.25)+1/8" (3.18) - 0+/-10.0%
4" (101.6)0.083" (2.11)+/-0.015" (0.38)+1/8" (3.18) - 0+/-10.0%
6" (152.4)0.083" (2.11)+/-0.030" (0.76)+1" (25.4) - 0+/-10.0%
6" (152.4)0.109" (2.77)+/-0.030" (0.76)+1" (25.4) - 0+/-10.0%
8" (203.2)0.109" (2.77)+0.061" (1.55)/-0.031" (0.79)+1" (25.4) - 0+/-10.0%



ASME SA249 ERW Bright Annealed Duplex Stainless Steel Welded Tube For Heat Exchanger 0
