73.0X7.01MM TP304L Stainless Steel Welded Pipe Annealed Pickling
73.0X7.01MM TP304L Stainless Steel Welded Pipe Annealed Pickling 73.0X7.01MM TP304L Stainless Steel Welded Pipe Annealed Pickling
Contact Now

73.0X7.01MM TP304L Stainless Steel Welded Pipe Annealed Pickling

Minimum Order Quantity : negotiable Price : 2400-12000USD/TON
Packaging Details : Plywood Case / Bundles Delivery Time : 30 Days
Payment Terms : T / T ; L / C Supply Ability : 500 Tons / Month
Place of Origin: CHINA Brand Name: MTSCO
Certification: ISO 9001 & PED & AD2000 Model Number: MTSCOSSSP67

Detail Information
Material: TP304L /304 Size: 73.0MM*7.01MM
Surface: Annealed&Pickling Application: For Fluid & Gas Transport
NDT: Eddy Current Or Hydraulic Test Finish: PE
Length: 5800mm Inspection: 100%
High Light:

7.01MM Stainless Steel Welded Pipe

,

5800mm stainless steel welded tube

,

TP304L Stainless Steel Welded Pipe

Product Description

TP304L 73.0MM*7.01MM Annealed&Pickling Stainless Steel Welded Pipe



Stainless Steel Welded Pipe:



Welded industrial stainless steel pipe should be used in more low pressure, structural or ornamental applications, and welded is more cost-effective.



A major benefit of a welded stainless steel pipe is the price. Welded pipe on average is cheaper than seamless. Seamless has a limit on the range of possible sizes where welded does not.



Stainless Steel Welded Pipe Material :



American Standard TP304 , TP304L , TP310S , TP316 , TP316L , TP316Ti , TP321 , TP347 , 904L , S31803 Etc
European Standard 1.4301 , 1.4306 , 1.4845 , 1.4401 , 1.4404 , 1.4571 , 1.4541 , 1.4550 , 1.4539 , 1.4462 Etc
German Standard X5CrNi18-10 , X2CrNi19-11 , X12CrNi25-21 , X5CrNi17-12-2 , X5CrNi17-12-3 , X2CrNiMo18-14-3 , X6CrNiTi18-10 , X6CrNiTb18-10 Etc



Stainless Steel Welded Pipe Chemical Composition:



Chemical Composition % Max
C Mn P S Si Cr Ni Mo N B Nb Ti
TP304 0.08 2 0.045 0.03 1 18.0-20.0 8.0-11.0 ^ ^ ^. ^
TP304L 0.035 2 0.045 0.03 1 18.0-20.0 8.0-12.0 ^ ^ ^ ^
TP316 0.08 2 0.045 0.03 1 16.0-18.0 10.0-14.0 2.00-3.00 ^ ^ ^
TP316L 0.035 D 2 0.045 0.03 1 16.0-18.0 10.0-15.0 2.00-3.00 ^ ^ ^
TP321 0.08 2 0.045 0.03 1 17.0-19.0 9.0-12.0 ^ ^ ^ 5C -0.70
TP347 0.08 2 0.045 0.03 1 17.0-19.0 9.0-12.0 　 　 10C -1.10 ^



Stainless Steel Welded Pipe Industry Advantage:



Industry & Advantage Application a) For fluid & gas transport
b) Structure & machining etc
Advantages a) Advanced technology of cold draw machine
b) Advanced annealing machine
c) Better mechanical property
d) More precise dimension

e) Perfect inspection method and inspection equipment etc



Stainless Steel Welded Pipe Specifications :



DN NPS(Inch) D(mm) SCH5S SCH10S SCH10 SCH20 SCH30 STD SCH40 SCH60 SCH80 XS
300 12 323.9 3.96 4.57 - 6.35 8.38 9.53 10.31 14.27 17.48 12.7
350 14 355.6 3.96 4.78 6.35 7.92 9.53 9.53 11.13 15.09 19.05 12.7
400 16 406.4 4.19 4.78 6.35 7.92 9.53 9.53 12.7 16.66 21.44 12.7
450 18 457.2 4.19 4.78 6.35 7.92 11.13 9.53 14.27 19.05 23.83 12.7
500 20 508 4.78 5.54 6.35 9.53 12.7 9.53 15.09 20.62 26.19 12.7
550 22 559 4.78 5.54 6.35 9.53 12.7 9.53 - 22.23 28.58 12.7
600 24 610 5.54 6.35 6.35 9.53 14.27 9.53 17.48 24.61 30.96 12.7
650 26 660 - - 7.92 12.7 - 9.53 - - - 12.7
700 28 711 - - 7.92 12.7 15.88 9.53 - - - 12.7
750 30 762 6.35 7.92 7.92 12.7 15.88 9.53 - - - 12.7
800 32 813 - - 7.92 12.7 15.88 9.53 17.48 - - 12.7
850 34 864 - - 7.92 12.7 15.88 9.53 17.48 - - 12.7
900 36 914 - - 7.92 12.7 15.88 9.53 19.05 - - 12.7
950 38 965 - - - - - 9.53 - - - 12.7
1000 40 1016 - - - - - 9.53 - - - 12.7
1050 42 1067 - - - - - 9.53 - - - 12.7
1100 44 1118 - - - - - 9.53 - - - 12.7
1150 46 1168 - - - - - 9.53 - - - 12.7
1200 48 1219 - - - - - 9.53 - - - 12.7





73.0X7.01MM TP304L Stainless Steel Welded Pipe Annealed Pickling 0



Company Introduction
73.0X7.01MM TP304L Stainless Steel Welded Pipe Annealed Pickling 1

MTSCO established in 2006, during many years’ development, now becomes a large and professional industrial piping system provider,
serving customers from more than 100 countries and regions.


What products can MTSCO provide?



73.0X7.01MM TP304L Stainless Steel Welded Pipe Annealed Pickling 2



73.0X7.01MM TP304L Stainless Steel Welded Pipe Annealed Pickling 3

What materials can we provide?

Austenitic: 304/L/H/N,316/L/H/N/Ti,321/H,309/H,310S,347/H,317/L904L
Duplex steel: 31803,32205,32750,32760
Nickel Alloy:
UNS N10001, N10665, N10675, N06455, N06022, N10276, N06200, N06035, N06030, N06635, N10003, N06002, R30188, N06230,
R30556
UNS N06600, N06601, N06617, N06625, N07718, N07750, N08800, N08810, N08811, N08825, N09925, N08926
UNS N04400, N05500
Precipitation-hardening Steels: 254SMO/S31254, 17-4PH, 17-7PH, 15-7PH
Nickel: N4/UNS N02201, N6/UNS N02200

73.0X7.01MM TP304L Stainless Steel Welded Pipe Annealed Pickling 4
73.0X7.01MM TP304L Stainless Steel Welded Pipe Annealed Pickling 5

73.0X7.01MM TP304L Stainless Steel Welded Pipe Annealed Pickling 6



73.0X7.01MM TP304L Stainless Steel Welded Pipe Annealed Pickling 7
