100% PMI Test ASTM A249 / ASME SA249 Stainless Steel Tube For Fuild / Oil Industry
100% PMI Test ASTM A249 / ASME SA249 Stainless Steel Tube For Fuild / Oil Industry 100% PMI Test ASTM A249 / ASME SA249 Stainless Steel Tube For Fuild / Oil Industry 100% PMI Test ASTM A249 / ASME SA249 Stainless Steel Tube For Fuild / Oil Industry 100% PMI Test ASTM A249 / ASME SA249 Stainless Steel Tube For Fuild / Oil Industry
Contact Now

100% PMI Test ASTM A249 / ASME SA249 Stainless Steel Tube For Fuild / Oil Industry

Minimum Order Quantity : negotiable Price : 2500-12000USD/TON
Packaging Details : Plywood Case / Bundles Delivery Time : 25 Days
Payment Terms : T / T ; L / C Supply Ability : 500 Tons / Month
Place of Origin: CHINA Brand Name: MTSCO
Certification: ISO 9001 & PED Model Number: MTSCOSSWT11

Detail Information
Material: TP304 TP304L TP316 TP316L , 300 Series Stainless Steel Surface: 320 # Or 400 # Outside Polished
Delivery Condition: Soft / Hard Type: Welded
Process Method: ERW , EFW Etc PMI Test: 100%
High Light:

welded stainless steel tubing

,

welding round tube

Product Description

100% PMI Test ASTM A249 / ASME SA249 Stainless Steel Tube For Fuild / Oil Industry







ASTM A249 Standard :



Size OD Nominal Wall Outside Diameter Length Wall
1/2" (12.7) 0.065" (1.65)/0.049" (1.25) +/-0.005 (0.13) +1/8" (3.18) - 0 +/-10.0%
3/4" (19.1) 0.065" (1.65)/0.049" (1.25) +/-0.005 (0.13) +1/8" (3.18) - 0 +/-10.0%
1" (25.4) 0.065" (1.65)/0.049" (1.25) +/-0.005 (0.13) +1/8" (3.18) - 0 +/-10.0%
1-1/2" (38.1) 0.065" (1.65)/0.049" (1.25) +/-0.008" (0.20) +1/8" (3.18) - 0 +/-10.0%
2" (50.8) 0.065" (1.65)/0.049" (1.25) +/-0.008" (0.20) +1/8" (3.18) - 0 +/-10.0%
2-1/2" (63.5) 0.065" (1.65) +/-0.010" (0.25) +1/8" (3.18) - 0 +/-10.0%
3" (76.2) 0.065" (1.65) +/-0.010" (0.25) +1/8" (3.18) - 0 +/-10.0%
4" (101.6) 0.083" (2.11) +/-0.015" (0.38) +1/8" (3.18) - 0 +/-10.0%
6" (152.4) 0.083" (2.11) +/-0.030" (0.76) +1" (25.4) - 0 +/-10.0%
6" (152.4) 0.109" (2.77) +/-0.030" (0.76) +1" (25.4) - 0 +/-10.0%
8" (203.2) 0.109" (2.77) +0.061" (1.55)/-0.031" (0.79) +1" (25.4) - 0 +/-10.0%



Application :



a) For fluid and gas transport

b) Structure and machining

c) Heat exchanger pipes etc



DN NPS(Inch) D(mm) SCH5S SCH10S SCH10 SCH20 SCH30 STD SCH40 SCH60 SCH80 XS
300 12    323.9 3.96 4.57 - 6.35 8.38 9.53 10.31 14.27 17.48 12.7
350 14    355.6 3.96 4.78 6.35 7.92 9.53 9.53 11.13 15.09 19.05 12.7
400 16    406.4 4.19 4.78 6.35 7.92 9.53 9.53 12.7 16.66 21.44 12.7
450 18    457.2 4.19 4.78 6.35 7.92 11.13 9.53 14.27 19.05 23.83 12.7
500 20    508 4.78 5.54 6.35 9.53 12.7 9.53 15.09 20.62 26.19 12.7
550 22    559 4.78 5.54 6.35 9.53 12.7 9.53 - 22.23 28.58 12.7
600 24    610 5.54 6.35 6.35 9.53 14.27 9.53 17.48 24.61 30.96 12.7
650 26    660 - - 7.92 12.7 - 9.53 - - - 12.7
700 28    711 - - 7.92 12.7 15.88 9.53 - - - 12.7
750 30    762 6.35 7.92 7.92 12.7 15.88 9.53 - - - 12.7
800 32    813 - - 7.92 12.7 15.88 9.53 17.48 - - 12.7
850 34    864 - - 7.92 12.7 15.88 9.53 17.48 - - 12.7
900 36    914 - - 7.92 12.7 15.88 9.53 19.05 - - 12.7
950 38    965 - - - - - 9.53 - - - 12.7
1000 40    1016 - - - - - 9.53 - - - 12.7
1050 42    1067 - - - - - 9.53 - - - 12.7
1100 44    1118 - - - - - 9.53 - - - 12.7
1150 46    1168 - - - - - 9.53 - - - 12.7
1200 48    1219 - - - - - 9.53 - - - 12.7





MTSCO is a leading manufacturer who is specialized in stainless steel seamless pipes , bright annealed tubes , seamless coiled tubing etc . In order to facilitate customers , we have welded pipes and tubes too . MTSCO has the most advanced producing and testing equipment . Our products are always satisfied with customers . Customers purchased our products created more profits .



100% PMI Test ASTM A249 / ASME SA249 Stainless Steel Tube For Fuild / Oil Industry 0
