16SWG TP304 / S30400 ERW / EFW 3 / 8 Inch Stainless Steel Tubing Annealed & Pickled

Minimum Order Quantity :	negotiable	Price :	2500-12000USD/TON
Packaging Details :	Plywood Case / Bundles	Delivery Time :	25 Days
Payment Terms :	T / T ; L / C	Supply Ability :	500 Tons / Month

Place of Origin:	CHINA	Brand Name:	MTSCO
Certification:	ISO 9001 & PED & AD2000	Model Number:	MTSCOSSWT54

Detail Information
Material:	TP304 / 316	Surface:	Polished
Length:	6m	Type:	Welded
Process Method:	ERW , EFW Etc	PMI Test:	100%
Highlight:	welded stainless steel tubing , welding round tube

Product Description

3 / 8 Inch 16SWG TP304 / S30400 ERW / EFW Annealed & Pickled Stainless Steel Tube

Item	Description
Basic Information	Material Grade	TP304, TP304L, TP304H, TP316, TP316L, TP316Ti, TP309S, TP310S, TP321, TP321H, TP347, TP347H, etc
	Outer Diameter	3.18mm-101.6mm
	Wall Thickness	0.5mm-20mm
	Length	Normally fixed length 6m, can as per customer’s requirement
	Standard	ASTM A312; ASTM A269; ASTM A789; ASTM A790 ect.
	Process Method	ERW, EFW etc
Industry & Advantage	Application	a) For fluid and gas transport
		b) Structure and machining
		c) Heat exchanger pipes etc
	Advantages	a) Superior surface finish
		b) Better mechanical property
		c) More precise dimension
		d) Perfect inspection method and inspection equipment
Terms & Conditions	Price Item	FOB, CFR, CIF or as negotiation
	Payment	T/T, LC or as negotiation
	Delivery Time	30 working days after received your deposit (Normally according to the order quantity)
	Package	Iron case; woven bag or as per customer’s requirement
	Quality Requirement	Mill Test Certificate will be supplied with shipment, Third Part Inspection is acceptable
Quality	Test	X-ray, Size test, Length test
Quality	Test	Chemical Analysis(Photoelectric Emission Spectroscopic) etc
Market	Main Market	Europe, Middle East, Southeast Asia, South America. Etc

Specifications :

DN	NPS(Inch)	D(mm)	SCH5S	SCH10S	SCH40S	STD	SCH40	SCH80	XS	SCH80S	SCH160	XXS
6	1/8	10.30	-	1.24	1.73	1.73	1.73	2.41	2.41	2.41	-	-
8	1/4	13.70	-	1.65	2.24	2.24	2.24	3.02	3.02	3.02	-	-
10	3/8	17.10	-	1.65	2.31	2.31	2.31	3.20	3.20	3.20	-	-
15	1/2	21.30	1.65	2.11	2.77	2.77	2.77	3.73	3.73	3.73	4.78	7.47
20	3/4	26.70	1.65	2.11	2.87	2.87	2.87	3.91	3.91	3.91	5.56	7.82
25	1	33.40	1.65	2.77	3.38	3.38	3.38	4.55	4.55	4.55	6.35	9.09
32	1 1/4	42.20	1.65	2.77	3.56	3.56	3.56	4.85	4.85	4.85	6.35	9.70
40	1 1/2	48.30	1.65	2.77	3.68	3.68	3.68	5.08	5.08	5.08	7.14	10.15
50	2	60.30	1.65	2.77	3.91	3.91	3.91	5.54	5.54	5.54	8.74	11.07
65	2 1/2	73.00	2.11	3.05	5.16	5.16	5.16	7.01	7.01	7.01	9.53	14.02
80	3	88.90	2.11	3.05	5.49	5.49	5.49	7.62	7.62	7.62	11.13	15.24
90	3 1/2	101.60	2.11	3.05	5.74	5.74	5.74	8.08	8.08	8.08	-	-
100	4	114.30	2.11	3.05	6.02	6.02	6.02	8.56	8.56	8.56	13.49	17.12
125	5	141.30	2.77	3.40	6.55	6.55	6.55	9.53	9.53	9.53	15.88	19.05
150	6	168.30	2.77	3.40	7.11	7.11	7.11	10.97	10.97	10.97	18.26	21.95
200	8	219.10	2.77	3.76	8.18	8.18	8.18	12.70	12.70	12.70	23.01	22.23
250	10	273.10	3.40	4.19	9.27	9.27	9.27	15.09	12.70	12.70	28.58	25.40

16SWG TP304 / S30400 ERW / EFW 3 / 8 Inch Stainless Steel Tubing Annealed & Pickled 0

Stanard Wire Gauge ( Fomerly Imperial Wire Gauge ) SWG
SWG	Wall Thickness		SWG	Wall Thickness
12	0.104	2.64	33	0.01	0.25
13	0.092	2.34	34	0.0092	0.23
14	0.08	2.03	35	0.0084	0.21
15	0.072	1.83	36	0.0076	0.19
16	0.064	1.63	37	0.0068	0.17
17	0.056	1.42	38	0.006	0.15
18	0.048	1.22	39	0.0052	0.13
19	0.04	1.02	40	0.0048	0.12
20	0.036	0.91

MTSCO is a leading manufacturer who is specialized in stainless steel seamless pipes , bright annealed tubes , seamless coiled tubing etc . In order to facilitate customers , we have welded pipes and tubes too . MTSCO has the most advanced producing and testing equipment . We can totally satisfy your requirement . According to standard very strictly , tubes which produced by us always have correct OD and WT tolerance . The tolerance control is strictly accordance to produce standards . Our products are always satisfied with customers . Customers purchased our products created more profits .
