Bright Annealed Nickel Alloy Tube , ISO 9001 / PED , ANSI B36.19 ASTM B829 / ASME SB829 , ASTM B167 , ASTM B444

Minimum Order Quantity : negotiable Price : 25000-100000USD/TON
Packaging Details : Plywood Case Delivery Time : 30 Days
Payment Terms : T / T ; L / C Supply Ability : 300 Tons / Month
Place of Origin : CHINA Brand Name : ERAUM
Certification : ISO 9001 & PED Model Number : MTSCONAT14

Detail Information

Material: Inc 600 / 601 / 625 / 800 / 825 Etc / Nickel Alloy Steel Surface: Bright Annealed / Pickling
Technology: Cold Drawn / Cold Rolled Length: 6m Fixed Length
NDT: Eddy Current Or Hydraulic Test Inspection: 100%

Product Description

Bright Annealed Nickel Alloy Tube , ISO 9001 / PED , ANSI B36.19 ASTM B829 / ASME SB829 , ASTM B167 , ASTM B444







Item

Description

Basic Information

Material Grade

 UNS N06625,  N06600, N06601,N07718, N10276,N08800, N08825, N04400; etc

Outer Diameter

3.18mm-101.6mm

Wall Thickness

0.5mm-20mm

Length

Normally fixed length 6m, can as per customer’s requirement

Standard

ASTM B163; ASTM B167; ASTM B444; ASTM B622 ect

Process Method

Cold Drawn or Cold Rolled

Industry & Advantage

Application

a) Heat exchanger

b) Condenser

c) Shipping industry

d) Precision machinery

e) Mechanical structure industry

f) Thermocouple & Cable etc

Advantages

a) Superior surface finish

b) Better mechanical property

c) More precise dimension

d) Perfect inspection method and inspection equipment

Terms & Conditions

Price Item

FOB, CFR, CIF or as negotiation

Payment

T/T, LC or as negotiation

Delivery Time

30 working days after received your deposit (Normally according to the order quantity)

Package

Iron case; woven bag or as per customer’s requirement

Quality Requirement

Mill Test Certificate will be supplied with shipment, Third Part Inspection is acceptable

Quality

Test

NTD(Ultrasonic test, Eddy Current test)

Mechanical Test(Tension Test, Flaring Test, Flattening Test, Hardness Test, Hydraulic test)

Metal Test(Metallographic Analysis, Impact Test-High/low temperature)

Chemical Analysis(Photoelectric Emission Spectroscopic)

Market

Main Market

Europe, Middle East, Southeast Asia, South America. etc



ANSI B36.19 ASTM B829 / ASME SB829 Specifications :



NPS Designator Outside Diameter Nominal Wall Thickness
in. mm Schedule 5S Schedule 10S Schedule 4S Schedule 80S
      in. mm in. mm in. mm in. mm
 1 / 8 0.405 10.29 0.049 1.24 0.068 1.73 0.095 2.41
 1 / 4 0.54 13.72 0.065 1.65 0.088 2.24 0.119 3.02
 3 / 8 0.675 17.15 0.065 1.65 0.091 2.31 0.126 3.2
 1 / 2 0.84 21.34 0.065 1.65 0.083 2.11 0.109 2.77 0.147 3.73
 3 / 4 1.05 26.67 0.065 1.65 0.083 2.11 0.113 2.87 0.154 3.91
1 1.315 33.4 0.065 1.65 0.109 2.77 0.133 3.38 0.179 4.55
1 1 / 4 1.66 42.16 0.065 1.65 0.109 2.77 0.14 3.56 0.191 4.85
1 1 / 2 1.9 48.26 0.065 1.65 0.109 2.77 0.145 3.68 0.2 5.08
2 2.375 60.33 0.065 1.65 0.109 2.77 0.154 3.91 0.218 5.54
2 1 / 2 2.875 73.03 0.083 2.11 0.12 3.05 0.203 5.16 0.276 7.01
3 3.5 88.9 0.083 2.11 0.12 3.05 0.216 5.49 0.3 7.62
3 1 / 2 4 101.6 0.083 2.11 0.12 3.05 0.226 5.74 0.318 8.08
4 4.5 114.3 0.083 2.11 0.12 3.05 0.237 6.02 0.337 8.56
5 5.563 141.3 0.109 2.77 0.134 3.4 0.258 6.55 0.375 9.52
6 6.625 168.28 0.109 2.77 0.134 3.4 0.28 7.11 0.432 10.97
8 8.625 219.08 0.109 2.77 0.148 3.76 0.322 8.18 0.5 12.7
10 10.75 273.05 0.134 3.4 0.165 4.19 0.365 9.27 0.5 12.7
12 12.75 323.85 0.156 3.96 0.18 4.57 0.375 9.52 0.5 12.7
14 14 355.6 0.156 3.96 0.188 4.78
16 16 406.4 0.165 4.19 0.188 4.78
18 18 457.2 0.165 4.19 0.188 4.78
20 20 508 0.188 4.78 0.218 5.54
22 22 558.8 0.188 4.78 0.218 5.54
24 24 609.6 0.218 5.54 0.25 6.35
30 30 762 0.25 6.35 0.312 7.92



Bright Annealed Nickel Alloy Tube , ISO 9001 / PED , ANSI B36.19 ASTM B829 / ASME SB829 , ASTM B167 , ASTM B444



MTSCO is a leading manufacturer who is specialized in stainless steel seamless pipes , bright annealed tubes , seamless coiled tubing etc basic products . We also have duplex stainless steel tubes and pipes , nickel alloy tubes and pipes etc . MTSCO has the most advanced producing and testing equipment . We can totally satisfy your requirement .

According to standard very strictly, nickel alloy tubes which produced by us always have correct OD and WT tolerance . Nickel alloy tubes have a very important position in thermocouple & cable industry .
