DN 60 80 100 Stainless Steel Annealed & Pickled Seamless Pipe For Gas Transportation

Minimum Order Quantity :	negotiable	Price :	2900-10000USD/TON
Packaging Details :	Plywood Case	Delivery Time :	30 Days
Payment Terms :	T / T ; L / C	Supply Ability :	300 Tons / Month

Place of Origin:	CHINA	Brand Name:	MTSCO
Certification:	ISO 9001 & PED & AD2000	Model Number:	MTSCOSSSP26

Detail Information
Material:	Stainless Steel TP304 TP304L TP316 TP316L , 300 Series	Delivery Condition:	Soft / Hard
NDT:	Eddy Current Or Hydraulic Test	End Cut:	Plain End ( PE ) / Bevel End ( BE )
Type:	Seamless	Inspection:	100%
Highlight:	seamless stainless pipe , seamless stainless tube

Product Description

DN60, 80, 100 Stainless Steel Annealed & Pickled Seamless Pipe For Fuild And Gas Transportation

Specifications :

DN	NPS(Inch)	D(mm)	SCH5S	SCH10S	SCH40S	STD	SCH40	SCH80	XS	SCH80S	SCH160	XXS
40	1 1/2	48.30	1.65	2.77	3.68	3.68	3.68	5.08	5.08	5.08	7.14	10.15
50	2	60.30	1.65	2.77	3.91	3.91	3.91	5.54	5.54	5.54	8.74	11.07
65	2 1/2	73.00	2.11	3.05	5.16	5.16	5.16	7.01	7.01	7.01	9.53	14.02
80	3	88.90	2.11	3.05	5.49	5.49	5.49	7.62	7.62	7.62	11.13	15.24
90	3 1/2	101.60	2.11	3.05	5.74	5.74	5.74	8.08	8.08	8.08	-	-
100	4	114.30	2.11	3.05	6.02	6.02	6.02	8.56	8.56	8.56	13.49	17.12

Project	Standard	ASTM A269/A269M	ASTM A312/A312M	ASTM A213/A213M	ASTM A789/789M	ASTM A790/790M
Grade		TP304 TP304L TP321 TP316 TP316L TP317 TP321 TP347 N08904/904L	TP304 TP304L TP309S TP310S TP316 TP316L TP316Ti TP317 TP317L TP321 TP347	TP304 TP304L TP309S TP316 TP316L TP316Ti TP317 TP310S TP321 TP347	S32250 S31803 S32750	S32250 S31803 S32750
Size		NPS:1/8”-48” SCH:5S,10/10S,20,30,40/40S,60,80/80S,100,120,140,160,STD,XS,XXS OD:10.3mm-1219mm WT:1.24mm-59.54mm
Length		According to customer’s request, Max. 18Meters.

DN 60 80 100 Stainless Steel Annealed & Pickled Seamless Pipe For Gas Transportation 0

Industry & Advantage	Application	a) For fluid & gas transport
		b) Structure & machining etc
	Advantages	a) Advanced technology of cold draw machine
		b) Advanced annealing machine
		c) Better mechanical property
		d) More precise dimension
		e) Perfect inspection method and inspection equipment etc

MTSCO has been dedicated to producing seamless stainless steel pipe since 2003 , owning complete producing technology and abundant managing experience . Our raw material such as mother tube , round bar we use is from Chinese biggest and well known steel mill : Walsin , Yongxing etc . And We have advanced NDT equipments for the tests such as Eddy Current test, Ultrasonic test , Hydraulic test and so on . We have ISO 9001 and PED certificate , and the Third Party Inspection Certificates such as TUV , BV , Lloyd’s , SGS , etc , also can be provided according to customers’ requirements .
