Detail Information
Material:	TP347 / 347H	Standard:	ASTM A269 / ASTM A213 Dual Standards Etc
Delivery Condition:	Soft / Hard	Type:	Welded
Surface:	Bright Annealed / Pickled	Feature:	Flame Retardant
High Light:	coiled stainless tube , seamless stainless steel pipe

Product Description

1 / 4 Inch Sch10s TP347 / 347H Stainless Steel Welded Multi-core Coiled Tubing

The multi-core tube consists of one to nine stainless steel tubes laid up spirally inside an extruded outer PVC sheath. For easy identification and protection purposes each individual tube is PVC sheathed in a different color. The extruded outer sheath is made of oil and seawater resistant, weatherproof, flame retardant, corrosion and acid resistant PVC. The multi-core tube (outer sheath) is continuously marked at every one meter throughout the entire length for easy installation. Heat shrinkable products provide complete water sealing, abrasion and corrosion protection under all conditions.

Chemical Composition

	C(max)	Si(max)	Mn(max)	P(max)	S(max)	Cr	Ni	Mo	Ti
TP304/1.4301	0.080	1.00	2.00	0.045	0.030	18.0-20.0	8.0-10.5
TP304L/1.4307	0.035	1.00	2.00	0.045	0.030	18.0-20.0	8.0-12.0
TP304H/1.4948	0.04-0.10	1.00	2.00	0.045	0.030	18.0-20.0	8.0-12.0
TP316/1.4401	0.080	1.00	2.00	0.045	0.030	16.0-18.0	11.0-14.0	2.0-3.0
TP316L/1.4404	0.035	1.00	2.00	0.045	0.030	16.0-18.0	10.0-14.0	2.0-3.0
TP316Ti/1.4571	0.080	1.00	2.00	0.045	0.030	16.0-18.0	10.0-14.0	2.0-3.0	0.7>5x(C+N)
TP321/1.4541	0.080	1.00	2.00	0.045	0.030	17.0-19.0	9.0-12.0		0.7>5x(C+N)
TP317L/1.4449	0.080	1.00	2.00	0.045	0.030	18.0-20.0	11.0-14.0	3.0-4.0
TP347H/1.4912	0.04-0.10	1.00	2.00	0.045	0.030	17.0-19.0	9.0-13.0
TP309S/1.4833	0.080	1.00	2.00	0.045	0.030	22.0-24.0	12.0-15.0	0.75
TP310S/1.4845	0.080	1.00	2.00	0.045	0.030	24.0-26.0	19.0-22.0	0.75

1 / 4 Inch Sch10s coiled stainless steel tubing 0

Ordering code number	Tube size (O.D x Thickness x Core)	Overall Diameter (.mm)	Sheath Thickness (.mm)	Bundle Weight (kg/M)	Max Pressure (Bar)
HTD-1	6×1.0×1	8	1.0	0.15	Working:180Bar Test:270Bar
HTD-2	6×1.0×2	20	2.0	0.60
HTD-3	6×1.0×3	21	2.0	0.75
HTD-4	6×1.0×4	24	2.0	0.82
HTD-5	6×1.0×5	25	2.0	0.90
HTD-6	6×1.0×6	27	2.0	1.04
HTD-7	6×1.0×7	27	2.0	1.15
HTD-8	6×1.0×8	32	2.2	1.40
HTD-9	8×1.0×1	10	1.0	0.28
HTD-10	8×1.0×2	24	1.8	0.89
HTD-11	8×1.0×3	26	2.0	1.12
HTD-12	8×1.0×4	28	2.0	1.33
HTD-13	8×1.0×5	31	2.0	1.67
HTD-14	8×1.0×6	34	2.0	2.00
HTD-15	8×1.0×7	34	2.0	2.15
HTD-16	8×1.0×8	40	2.2	2.60
HTD-17	10×1.0×1	13	1.0	0.34
HTD-18	10×1.0×2	28	1.8	1.18
HTD-19	10×1.0×3	31	2.0	1.60
HTD-20	10×1.0×4	34	2.0	1.97
HTD-21	10×1.0×5	37	2.0	2.20
HTD-22	10×1.0×6	40	2.0	2.40
HTD-23	10×1.0×7	40	2.0	2.52
HTD-24	10×1.0×8	48	2.5	3.20
HTD-25	12×1.0×1	14	1.0	0.41
HTD-26	12×1.0×2	34	2.0	1.35
HTD-27	12×1.0×3	36	2.0	1.96
HTD-28	12×1.0×4	39	2.0	2.37
HTD-29	12×1.0×5	43	2.0	2.70
HTD-30	12×1.0×6	47	2.0	3.00
HTD-31	12×1.0×7	47	2.0	3.14
HTD-32	12×1.0×8	55	2.5	3.90

Tag:

Product Details:
Place of Origin:	CHINA
Brand Name:	MTSCO
Certification:	ISO 9001 & PED & AD2000
Model Number:	MTSCOSSCT59
Payment & Shipping Terms:
Minimum Order Quantity:	negotiable
Price:	5500-10000USD/TON
Packaging Details:	Iron Case / Plywood Case
Delivery Time:	30 Days
Payment Terms:	T / T ; L / C
Supply Ability:	300 Tons / Month
