ASTM A789 1.4462 / S32205 duplex stainless steel tube With Good Impact Toughness

China ASTM A789 1.4462 / S32205 duplex stainless steel tube With Good Impact Toughness supplier
ASTM A789 1.4462 / S32205 duplex stainless steel tube With Good Impact Toughness supplier ASTM A789 1.4462 / S32205 duplex stainless steel tube With Good Impact Toughness supplier

Large Image :  ASTM A789 1.4462 / S32205 duplex stainless steel tube With Good Impact Toughness

Product Details:

Place of Origin: CHINA
Brand Name: MTSCO
Certification: ISO 9001 & PED & AD2000
Model Number: MTSCODST51

Payment & Shipping Terms:

Minimum Order Quantity: negotiable
Price: 5500-10000USD/TON
Packaging Details: Iron Case / Plywood Case
Delivery Time: 30 Days
Payment Terms: T / T ; L / C
Supply Ability: 300 Tons / Month
Contact Now
Detailed Product Description
Material: S32750 /S31803/ S32760 /S32550 / S32205 / Etc Type: Seamless
Standard: ASTM A789 / ASME SA789 / ASTM A790 / ASME SA790 Etc NDT: Eddy Current Or Hydraulic Test
Inspection: 100 % Delivery Condition: Soft / Hard

ASTM A789 1.4462 / S32205 Stainless Steel Duplex Tube With Good Impact Toughness









Material Grade: S32205 , S31803 , S32304 , S32750, F51 , F53 , 2205 , 2507 etc

Outer Diameter: 3.18mm - 101.6mm

Wall Thickness: 0.5mm - 20mm

Length: as per customer’s requirement

StandardASTM A789 ; ASTM A790 ; EN 10216-5 etc.



UNS Designation C Si Mn P S Cr Ni Mo N Cu
 max max max max max
S31803 0.03 1 2 0.03 0.02 21.0 - 23.0 4.5 - 6.5 2.5 - 3.5 0.08 - 0.20 -
S32205 0.03 1 2 0.03 0.02 22.0 - 23.0 4.5 - 6.5 3.0 - 3.5 0.14 - 0.20 -
S32750 0.03 0.8 1.2 0.035 0.02 24.0 - 26.0 6.0 - 8.0 3.0 - 5.0 0.24 - 0.32 0.5 max
S32760 0.05 1 1 0.03 0.01 24.0 - 26.0 6.0 - 8.0 3.0 - 4.0 0.20 - 0.30 0.50 -1.00







Terms & Conditions Price Item FOB, CFR, CIF or as negotiation
Payment T/T, LC or as negotiation
Delivery Time   30 working days after received your deposit (Normally according to the order quantity)
Package Iron case; woven bag or as per customer’s requirement
Quality Requirement Mill Test Certificate will be supplied with shipment, Third Part Inspection is acceptable
Quality Test NTD(Ultrasonic test, Eddy Current test);
Mechanical Test(Tension Test, Flaring Test, Flattening Test, Hardness Test, Hydraulic test);
Metal Test(Metallographic Analysis, Impact Test-High/low temperature);
Chemical Analysis(Photoelectric Emission Spectroscopic)
Market Main Market Europe, Middle East, Southeast Asia, South America. etc



Features :


1 . Outstanding resistance to pitting and crevice corrosion in seawater and other chloride containing environments, with critical pitting temperature exceeding 50°C
2 . Excellent ductility and impact strength at both ambient and sub-zero temperatures
3 . High resistance to abrasion, erosion and cavitation erosion
4 . Excellent resistance to stress corrosion cracking in chloride containing environments
5 . ASME approval for pressure vessel application



Super duplex stainless such as duplex is a mixed microstructure of austenite and ferrite which has improved strength over ferritic and austenitic steel grades . The main difference is super duplex has a higher molybdenum and chromium content which gives the material greater corrosion resistance . Super duplex has the same benefits as its counterpart - it has lower production costs when compared with similar ferritic and austenitic grades and due to the materials increased tensile and yield strength , in many cases this gives the purchaser the welcomed option of purchasing smaller thicknesses without the need to compromise on quality and performance .
