TP304/TP304L 60.3MM*5.54MM Annealed Stainless Steel Welded Pipe

Minimum Order Quantity : negotiable Price : 2400-12000USD/TON
Packaging Details : Plywood Case / Bundles Delivery Time : 30 Days
Payment Terms : T / T ; L / C Supply Ability : 500 Tons / Month
Place of Origin: CHINA Brand Name: MTSCO
Certification: ISO 9001 & PED & AD2000 Model Number: MTSCOSSSP59

Detail Information

Material: TP304L /304 Size: 2 Inch
NDT: Eddy Current Or Hydraulic Test Inspection: 100%
Surface: Annealed Length: 5800mm
High Light:

60.3MM*5.54MM Stainless Steel Welded Pipe

,

TP304 Stainless Steel Welded Pipe

,

TP304L annealed stainless steel tubing

Product Description

TP 304/304L 60.3MM*5.54MM Annealed Stainless Steel welded Pipe





Chemical Composition :



Material ASTM A269 Chemical Composition % Max
C Mn P S Si Cr Ni Mo N B Nb Ti
TP304 0.08 2 0.045 0.03 1 18.0-20.0 8.0-11.0 ^ ^ ^. ^
TP304L 0.035 2 0.045 0.03 1 18.0-20.0 8.0-12.0 ^ ^ ^ ^
TP316 0.08 2 0.045 0.03 1 16.0-18.0 10.0-14.0 2.00-3.00 ^ ^ ^
TP316L 0.035 D 2 0.045 0.03 1 16.0-18.0 10.0-15.0 2.00-3.00 ^ ^ ^
TP321 0.08 2 0.045 0.03 1 17.0-19.0 9.0-12.0 ^ ^ ^ 5C -0.70
TP347 0.08 2 0.045 0.03 1 17.0-19.0 9.0-12.0     10C -1.10 ^





Test :



1 . X-ray , Size test , Length test

2 . Chemical Analysis ( Photoelectric Emission Spectroscopic ) etc



Industry & Advantage Application a) For fluid & gas transport
b) Structure & machining etc
Advantages a) Advanced technology of cold draw machine
b) Advanced annealing machine
c) Better mechanical property
d) More precise dimension

e) Perfect inspection method and inspection equipment etc



Specifications :



DN NPS(Inch) D(mm) SCH5S SCH10S SCH10 SCH20 SCH30 STD SCH40 SCH60 SCH80 XS
300 12 323.9 3.96 4.57 - 6.35 8.38 9.53 10.31 14.27 17.48 12.7
350 14 355.6 3.96 4.78 6.35 7.92 9.53 9.53 11.13 15.09 19.05 12.7
400 16 406.4 4.19 4.78 6.35 7.92 9.53 9.53 12.7 16.66 21.44 12.7
450 18 457.2 4.19 4.78 6.35 7.92 11.13 9.53 14.27 19.05 23.83 12.7
500 20 508 4.78 5.54 6.35 9.53 12.7 9.53 15.09 20.62 26.19 12.7
550 22 559 4.78 5.54 6.35 9.53 12.7 9.53 - 22.23 28.58 12.7
600 24 610 5.54 6.35 6.35 9.53 14.27 9.53 17.48 24.61 30.96 12.7
650 26 660 - - 7.92 12.7 - 9.53 - - - 12.7
700 28 711 - - 7.92 12.7 15.88 9.53 - - - 12.7
750 30 762 6.35 7.92 7.92 12.7 15.88 9.53 - - - 12.7
800 32 813 - - 7.92 12.7 15.88 9.53 17.48 - - 12.7
850 34 864 - - 7.92 12.7 15.88 9.53 17.48 - - 12.7
900 36 914 - - 7.92 12.7 15.88 9.53 19.05 - - 12.7
950 38 965 - - - - - 9.53 - - - 12.7
1000 40 1016 - - - - - 9.53 - - - 12.7
1050 42 1067 - - - - - 9.53 - - - 12.7
1100 44 1118 - - - - - 9.53 - - - 12.7
1150 46 1168 - - - - - 9.53 - - - 12.7
1200 48 1219 - - - - - 9.53 - - - 12.7





   MTSCO has been dedicated to producing welded pipe and tube since 2003 , owning complete producing technology and abundant managing experience . And we have ISO 9001 and PED certificate , and the Third Party Inspection Certificates such as TUV , BV , Lloyd’s , SGS , etc , also can be provided according to customers’ requirements .

   MTSCO is a leading manufacturer who is specialized in stainless steel seamless pipes , bright annealed tubes ,  seamless coiled tubing etc . In order to facilitate customers, we have welded pipes and tubes too. MTSCO has the most advanced producing and testing equipment . We can totally satisfy your requirement . According to standard very strictly , pipes which produced by us always have correct OD and WT tolerance .
