1/4" UNS N06625 Oilfield Encapsulated Control Line 3 lines With Flat Pack

Minimum Order Quantity : negotiable Price : 5500-10000USD/TON
Packaging Details : Wood spool Delivery Time : 30 Days
Payment Terms : T / T ; L / C Supply Ability : 300 Tons / Month
Place of Origin: CHINA Brand Name: MTSCO
Certification: ISO 9001 & PED Model Number: MTSCOSSCT05

Detail Information

Material: Alloy625/ UNS N06625 Standard: ASTM A704
Size: 1/4";3/8";1/2" Length: According To Customer's Requirement
Type: Welded Material Type: Stainless Steel; Duplex Steel; Nickel Alloy
Inspection: Hydrostatic Test; NDT Application: Oilfield/Natural Gas/Ship Building/Cable
Advantage: Improve The Efficiency Of Oil Exploitation Additional Material: PVDF Etc
High Light:

UNS N06625 encapsulated control line

,

ASTM B704 encapsulated control line

,

UNS N06625 coiled line pipe

Product Description

1/4" UNS N06625 Oilfield Encapsulated Control Line 3lines With Flat Pack





An increasing number of projects in the oil service industry require the use of continuous lengths of stainless steel control lines. They are used in a variety of applications, including chemical injection, hydraulic control, instrumentation umbilicals and flowline control.

MTSCO offers products for all of these applications, helping customers reduce operating costs and improve recovery methods.



Control Line Technical Details:



  line 1 line 2 line 3
Outside diameter (in) 1/4" 1/4" 1/4"
Wall thickness (in) 0.049" 0.049" 0.035"
Color coding According to customer's request
Flush and Filling Oil
Manufacturing specification ASTM B704 ASTM B704 ASTM B704
Yield strength (psi) ≥34954 ≥34954 ≥34954
Test Pressure (psi) 5000 5000 5000
Maximum Hardness (HB) 85-90HRb 85-90HRb 85-90HRb
Tolerance: WT(%) OD (mm) WT ±5% OD±0.003 WT ±5% OD±0.003 WT ±5% OD±0.003





Material: TP316L, S32205, Alloy825/N08825, Alloy400/ N04400, Alloy625 N06625 1/4" UNS N06625 Oilfield Encapsulated Control Line 3 lines With Flat Pack 0
Outer Diameter: 1/4“, 3/8”,1/2“
Wall Thickness: 0.035”,0.049“,0.065”
Length : PER FT
Application : Inhibitor Supply control

Pressure Rating : 15000 Psi

Type : HYDRAULIC FLAT PACK
Additional Material Specs : PVDF Encapsulation



Size : 3lines x 1/4" 0.049WT



Additional Features : Color coded, oil filling, fluid filling



Encapsulation Size : 33 x 11mm







MTSCO has been supplying industrial tubing to the oil and gas industry for more than a decade. In recent years, we have continued to make breakthroughs in the field of coiled tubing, downhole control lines, and chemical injection control lines. Our coiled tubing has been successfully used in certain harsh subsea and downhole conditions, and through continuous research and development, is able to meet the stringent quality requirements of the oil and gas industry and other industries.



1/4" UNS N06625 Oilfield Encapsulated Control Line 3 lines With Flat Pack 1 1/4" UNS N06625 Oilfield Encapsulated Control Line 3 lines With Flat Pack 2









About MTSCO:



Who MTSCO IS?



MTSCO established in 2006, during many years’ development, now becomes a large and professional industrial piping system provider, serving customers from more than 100 countries and regions.



1/4" UNS N06625 Oilfield Encapsulated Control Line 3 lines With Flat Pack 3



What products can MTSCO provide?





1/4" UNS N06625 Oilfield Encapsulated Control Line 3 lines With Flat Pack 4



1/4" UNS N06625 Oilfield Encapsulated Control Line 3 lines With Flat Pack 5



What materials can MTSCO provide?



Austenitic: 304/L/H/N,316/L/H/N/Ti,321/H,309/H,310S,347/H,317/L904L

Duplex steel: 31803,32205,32750,32760

Nickel Alloy:

UNS N10001, N10665, N10675, N06455, N06022, N10276, N06200, N06035, N06030, N06635, N10003, N06002, R30188, N06230, R30556

UNS N06600, N06601, N06617, N06625, N07718, N07750, N08800, N08810, N08811, N08825, N09925, N08926

UNS N04400, N05500

Precipitation-hardening Steels: 254SMO/S31254, 17-4PH, 17-7PH, 15-7PH

Nickel: N4/UNS N02201, N6/UNS N02200



How can MTSCO service customers?



MTSCO's ISO9001 Quality System is issued by TUV. Our full and professional inspection reports contain two parts, one is self-inspection of the requirements beyond ISO9001, which is 100% inspected by our own QC; another is 100% inspected by professional QC teams.



1/4" UNS N06625 Oilfield Encapsulated Control Line 3 lines With Flat Pack 6



For more information, you are welcome to contact us by email. Thank you for your interest.
