ASTM B167 UNS N04400 Nickel Alloy 400 Tube For Chemical Process Equipment

Minimum Order Quantity : negotiable Price : 25000-100000USD/TON
Packaging Details : Plywood Case Delivery Time : 30 Days
Payment Terms : T / T ; L / C Supply Ability : 300 Tons / Month
Place of Origin: CHINA Brand Name: ERAUM/MTSCO
Certification: ISO 9001 & PED Model Number: MTSCONAT86

Detail Information

Material: Nickel Alloy Grade: UNS N04400/ Alloy 400
Outer Diameter: 6mm~457mm Standard: ASTM B167
Type: Seamless Technology: Cold Drawn / Cold Rolled
Delivery Condition: Soft / Hard NDT: Eddy Current Or Hydraulic Test
Inspection: 100% Certificate: ISO9001/PED
High Light:

astm b167 UNS N04400

,

Nickel Alloy 400 Tube

,

UNS N04400 Tube

Product Description

ASTM B167 Nickel Alloy UNS N04400/ Nickel 400 Tube /Pipe For Chemical Process Equipment





Nickel 400 Tube:



MTSCO has the most advanced producing and testing equipment. We can totally satisfy your requirement. According to standard very strictly, nickel alloy tubes produced by us always have correct OD and WT tolerance. Nickel alloy tubes have a very important position in thermocouple & cable industry.



Main markets or alloy tubes include Europe, Middle East, Southeast Asia, South America, etc. MTSCO has bright annealing nickel alloy tube and pickling alloy tube. Compared these two kinds of tubes , bright annealed alloy tubes are more popular in the market. Because it has bright out and inner surface.


Nickel Alloy 400 Tube Material Grade:


1. Grade : Alloy 400 / N04400, Alloy 625 / N06625 , Alloy 600 / N06600 ,Alloy 601 / N06601 , Alloy 718 / N07718 , Alloy C276 / N10276 , Alloy 800 / N08000 ,  Alloy 825 / N08825 ; etc

2 . OD ( Outer Diameter ) : 6mm to 457mm

3 . WT ( Wall Thickness ) : 0.75mm to 20mm

4 . Length : As customer's requirement

5 . Standard : ASTM B163; ASTM B167; ASTM B444; ASTM B622 etc

6 . Technology : Cold Drawn / Cold Rolled



Monel 400 Tube Basic Information:



Industry & Advantage Application  Chemical process equipment, crude oil stills, gasoline and fresh water tanks, marine engineering equipment, valves, pumps and fasteners.
Advantages  Nickel 400 has excellent resistance to corrosion by many reducing media such as sulfuric and hydrochloric acids. It is generally more resistant to corrosion by oxidizing media than higher copper alloys. Alloy 400 resists pitting and stress corrosion cracking in most fresh and industrial waters. It has good resistance in flowing seawater, but under stagnant conditions, pitting and crevice corrosion is induced. Alloy 400 is probably the most resistant to hydrofluoric acid in all concentrations up to the boiling point, of all engineering alloys. Alloy 400 is notable for its toughness, it does not show embrittlement tendency at cryogenic temperatures. It is work hardenable.
Terms & Conditions Price Item  FOB, CFR, CIF or as negotiation
Payment  T/T, LC or as negotiation
Delivery Time  30 working days after received your deposit (Normally according to the order quantity)
Package  Iron case; woven bag or as per customer’s requirement
Quality Requirement  Mill Test Certificate will be supplied with shipment, Third Part Inspection is acceptable
Quality Test  NTD(Ultrasonic test, Eddy Current test)
 Mechanical Test(Tension Test, Flaring Test, Flattening Test, Hardness Test, Hydraulic test)
 Metal Test(Metallographic Analysis, Impact Test-High/low temperature)
 Chemical Analysis(Photoelectric Emission Spectroscopic)
Market Main Market  Europe, Middle East, Southeast Asia, South America. etc



Nickel Alloy 400 Tube Test :



1 . NTD(Ultrasonic test, Eddy Current test)

2 . Mechanical Test(Tension Test, Flaring Test, Flattening Test, Hardness Test, Hydraulic test)

3 . Metal Test(Metallographic Analysis, Impact Test-High/low temperature)

4 . Chemical Analysis(Photoelectric Emission Spectroscopic)



ASTM B167 UNS N04400 Nickel Alloy 400 Tube For Chemical Process Equipment 0



About MTSCO:



Who MTSCO is?



MTSCO established in 2006, during many years’ development, now becomes a large and professional industrial piping system provider, serving customers from more than 100 countries and regions.



ASTM B167 UNS N04400 Nickel Alloy 400 Tube For Chemical Process Equipment 1



What products can MTSCO provide?





ASTM B167 UNS N04400 Nickel Alloy 400 Tube For Chemical Process Equipment 2



ASTM B167 UNS N04400 Nickel Alloy 400 Tube For Chemical Process Equipment 3



What materials can MTSCO provide?



Austenitic: 304/L/H/N,316/L/H/N/Ti,321/H,309/H,310S,347/H,317/L904L

Duplex steel: 31803,32205,32750,32760

Nickel Alloy:

UNS N10001, N10665, N10675, N06455, N06022, N10276, N06200, N06035, N06030, N06635, N10003, N06002, R30188, N06230, R30556

UNS N06600, N06601, N06617, N06625, N07718, N07750, N08800, N08810, N08811, N08825, N09925, N08926

UNS N04400, N05500

Precipitation-hardening Steels: 254SMO/S31254, 17-4PH, 17-7PH, 15-7PH

Nickel: N4/UNS N02201, N6/UNS N02200



How can MTSCO service customers?



MTSCO's ISO9001 Quality System is issued by TUV. Our full and professional inspection reports contain two parts, one is self-inspection of the requirements beyond ISO9001, which is 100% inspected by our own QC; another is 100% inspected by professional QC teams.



ASTM B167 UNS N04400 Nickel Alloy 400 Tube For Chemical Process Equipment 4



For more information, you are welcome to contact us by email. Thank you for your interest.
