Alloy 625 Tube AP Straight Nickel Alloy Tube ISO High Temperature Environment For Heat Exchanger

Minimum Order Quantity : negotiable Price : 3700-9000USD/TON
Packaging Details : Plywood Case Delivery Time : 30 Days
Payment Terms : T / T ; L / C Supply Ability : 300 Tons / Month
Place of Origin: CHINA Brand Name: MTSCO
Certification: ISO 9001 & PED & AD2000 Model Number: MTSCOHET94

Detail Information

Material: Alloy 625/Alloy 600/Alloy 601/Alloy 800/Alloy 825 Standard: ASTM B622/ B516/ B444/ B829
Type: Welded/Seamless Length: According To Customer Needs Up To 20m
Technology: Cold Drawn / Cold Rolled Surface: Pickling
NDT: Eddy Current Or Hydraulic Test Inspection: 100%
Certificate: ISO9001/PED Packge: Wooden Case
High Light:

Nickel Alloy Tube ISO

,

AP Straight Nickel Alloy Tube

,

alloy 625 tube PED

Product Description

Alloy 625 Nickel Alloy A&P Straight Tube For Heat Exchanger With ISO In High Temperature Environment





Nickel Alloy 625 Application:



Low carbon alloy 625 after softening and annealing is widely used in chemical process industry. Its good corrosion resistance and high strength make it a thinner structural part. 625 alloy can be used in the case of contact with seawater and high mechanical stress. Typical application fields:

1. Components of organic chemical processes containing chlorides, especially when acid chloride catalysts are used

2. Digesters and bleachers for the pulp and paper industry

3. Absorber, reheater, flue gas inlet baffle, fan (wet), agitator, deflector and flue in flue gas desulfurization system

4. It is used to manufacture equipment and components used in acid gas environment

5 acetic acid and acetic anhydride reaction generator

6. Sulfuric acid condenser





Grade Alloy 625 / N06625 , Alloy C276 / N10276 ,Alloy 600 / N06600 ,Alloy 601 / N06601 , Alloy 718 / N07718 , Alloy 800 / N08000 , Alloy 825 / N08825 , Alloy 400 / N04400,etc

Standard



ASTM B622; ASTM B516; ASTM B444; ASTM B829, etc
Size OD :6mm-355.6mm
WT : 0.7mm-20mm
Length : According to customer needs up to 20m





Alloy 625 Tube AP Straight Nickel Alloy Tube ISO High Temperature Environment For Heat Exchanger 0




Product features

1. It has excellent corrosion resistance to various corrosive media in oxidation and reduction environment

2. Excellent resistance to pitting and crevice corrosion, and no stress corrosion cracking due to chloride

3. Excellent corrosion resistance to inorganic acids, such as nitric acid, phosphoric acid, sulfuric acid, hydrochloric acid and mixed acid of sulfuric acid and hydrochloric acid

4. Excellent corrosion resistance to mixed solution of various inorganic acids

5. When the temperature reaches 40 ℃, it can show good corrosion resistance in various concentrations of hydrochloric acid solution

6. Good processability and weldability, no cracking sensitivity after welding

7. Manufacturing certification of pressure vessel with wall temperature of - 196-450 ℃

8. It is certified by NACE standard of American Society of Corrosion Engineers (mr-01-75) to meet the highest standard level VII for acid gas environment







Nickel Alloy 625 Chemical composition:



% Ni Cr Mo Fe C Mn Si P S Co Nb+Ta Al Ti
min 58.0 20.0 8.0               3.15
max   23.0 10.0 5.0 0.10 0.50 0.50 0.015 0.015 1.00 4.15 0.40 0.40







Alloy 625 Tube AP Straight Nickel Alloy Tube ISO High Temperature Environment For Heat Exchanger 1





About MTSCO:



Who MTSCO is?



MTSCO established in 2006, during many years’ development, now becomes a large and professional industrial piping system provider, serving customers from more than 100 countries and regions.



Alloy 625 Tube AP Straight Nickel Alloy Tube ISO High Temperature Environment For Heat Exchanger 2



What products can MTSCO provide?





Alloy 625 Tube AP Straight Nickel Alloy Tube ISO High Temperature Environment For Heat Exchanger 3



Alloy 625 Tube AP Straight Nickel Alloy Tube ISO High Temperature Environment For Heat Exchanger 4



What materials can MTSCO provide?



Austenitic: 304/L/H/N,316/L/H/N/Ti,321/H,309/H,310S,347/H,317/L904L

Duplex steel: 31803,32205,32750,32760

Nickel Alloy:

UNS N10001, N10665, N10675, N06455, N06022, N10276, N06200, N06035, N06030, N06635, N10003, N06002, R30188, N06230, R30556

UNS N06600, N06601, N06617, N06625, N07718, N07750, N08800, N08810, N08811, N08825, N09925, N08926

UNS N04400, N05500

Precipitation-hardening Steels: 254SMO/S31254, 17-4PH, 17-7PH, 15-7PH

Nickel: N4/UNS N02201, N6/UNS N02200



How can MTSCO service customers?



MTSCO's ISO9001 Quality System is issued by TUV. Our full and professional inspection reports contain two parts, one is self-inspection of the requirements beyond ISO9001, which is 100% inspected by our own QC; another is 100% inspected by professional QC teams.



Alloy 625 Tube AP Straight Nickel Alloy Tube ISO High Temperature Environment For Heat Exchanger 5



Thank you very much for reading this, I wonder if my presentation will help you with your current problem? Looking forward to hearing from you!
