1.4438 TP317L Precision Stainless Steel Tubing ASTM A269 Standard 100% PMI Test
1.4438 TP317L Precision Stainless Steel Tubing ASTM A269 Standard 100% PMI Test 1.4438 TP317L Precision Stainless Steel Tubing ASTM A269 Standard 100% PMI Test 1.4438 TP317L Precision Stainless Steel Tubing ASTM A269 Standard 100% PMI Test 1.4438 TP317L Precision Stainless Steel Tubing ASTM A269 Standard 100% PMI Test
Contact Now

1.4438 TP317L Precision Stainless Steel Tubing ASTM A269 Standard 100% PMI Test

Minimum Order Quantity : negotiable Price : 6000-12000USD/TON
Packaging Details : Iron Case / Plywood Case Delivery Time : 30 Days
Payment Terms : T / T ; L / C Supply Ability : 300 Tons / Month
Place of Origin: CHINA Brand Name: MTSCO
Certification: ISO 9001 & PED & AD2000 Model Number: MTSCOPSST23

Detail Information
Material: 1.4438 / TP317L Length: 6096mm
Technology: Cold Drawn Condition: Soft / Hard
Type: Seamless Test: 100% PMI / EDT
High Light:

seamless stainless steel tubing

,

Cold Drawn Seamless Tube

,

Stainless Steel Precision Tubing

Product Description

1.4438 TP317L Precision Tubing , Stainless Steel Tube , ASTM A269 Standard







Chemical Composition——ASTM A269——304L ( wt% )

(C) Carbon, max: 0.035

(Mn) Manganese, max: 2

(P) Phosphorus, max: 0.045

(S) Sulfur, max: 0.03

(Si) Silicon, max: 1

(Ni) Nickel: 8.0-12.0

(Cr) Chromium: 18.0-20.0

(Mo) Molybdenum: N/A

(Fe) Iron: Bal.

(Cu) Copper: N/A

(N) Nitrogen: N/A



Applications :
1) . Petroleum , Chemical enterprise , Superheater of boiler , Heat exchanger
2) . High temperature resistant transmission fluid pipe in power station
3) . Ship with pressure pipe
4) . The exhaust purification device
5) . Construction and ornament : Escalator , Elevator , Doors Production tools , Kitchen appliances , Freezers , Cold rooms
6) . Equipment and Medical devices



Stanard Wire Gauge ( Fomerly Imperial Wire Gauge ) SWG
SWG Wall Thickness SWG Wall Thickness
0 0.324 8.23 21 0.032 0.81
1 0.3 7.62 22 0.028 0.71
2 0.276 7.01 23 0.024 0.61
3 0.252 6.4 24 0.022 0.56
4 0.232 5.89 25 0.02 0.51
5 0.212 5.38 26 0.018 0.46
6 0.192 4.88 27 0.0164 0.42
7 0.176 4.47 28 0.0148 0.38
8 0.16 4.06 29 0.0136 0.35
9 0.144 3.66 30 0.0124 0.31
10 0.128 3.25 31 0.0116 0.29
11 0.116 2.95 32 0.0108 0.27
12 0.104 2.64 33 0.01 0.25
13 0.092 2.34 34 0.0092 0.23
14 0.08 2.03 35 0.0084 0.21
15 0.072 1.83 36 0.0076 0.19
16 0.064 1.63 37 0.0068 0.17
17 0.056 1.42 38 0.006 0.15
18 0.048 1.22 39 0.0052 0.13
19 0.04 1.02 40 0.0048 0.12
20 0.036 0.91 　



1.4438 TP317L Precision Stainless Steel Tubing ASTM A269 Standard 100% PMI Test 0



MTSCO has the most advanced technology — The floating plug drawing technology which are used in Korea , and equipped with the most environmentally process — Bright annealing process . So our bright annealed precision tube produce technology make us can produce 300 tons high precision tubes every months .
