C276 UNS N10276 Material Nickel Alloy Tube Annealed Pickling For Heat Exchanger
Contact Person : Cherry Gao
Phone Number : +86 573 82717867
WhatsApp : +8613857354118
Minimum Order Quantity : | negotiable | Price : | 25000-100000USD/TON |
---|---|---|---|
Packaging Details : | Plywood Case | Delivery Time : | 30 Days |
Payment Terms : | T / T ; L / C | Supply Ability : | 300 Tons / Month |
Place of Origin: | CHINA | Brand Name: | MTSCO |
---|---|---|---|
Certification: | ISO 9001 & PED & AD2000 | Model Number: | MTSCONAT16 |
Detail Information |
|||
Material: | Alloy B-3/UNS N10675, Alloy C22/UNS N06022, Alloy 800/N08800,Alloy 825/N08825 Etc. | Outer Diameter: | 17.1-219.1mm |
---|---|---|---|
Surface: | Bright Annealed/Annealed Pickling | Technology: | Cold Drawn / Cold Rolled |
Length: | 6m Fixed Length | NDT: | Eddy Current Or Hydraulic Test |
Inspection: | 100% | Certificate: | ISO9001/PED |
Packge: | Wooden Case | ||
High Light: | nickel alloy pipe,nickel alloy tubing |
Product Description
ASTM B619 / B626 Alloy B-3 / UNS N10675 Nickel Alloy Welded Tube/Pipe For Chemical Industry
Item |
Description |
|
Basic Information |
Material Grade |
UNS N10276, UNS N10001, UNS N10665, UNS N10675, UNS N06022,N08800, N08825, N04400; etc |
Outer Diameter |
17.1-219.1mm |
|
Wall Thickness |
1.65mm-20mm |
|
Length |
Normally fixed length 6m, can as per customer’s requirement |
|
Standard |
ASTM B 619; ASTM B626; ASTM B444; ASTM B622 etc |
|
Process Method |
Cold Drawn or Cold Rolled |
|
Industry & Advantage |
Application |
Alloy B-3 / UNS N10675 alloy is suitable for use in all applications previously requiring the use of alloy B-2 alloy. Like B-2 alloy, B-3 is not recommended for use in the presence of ferric or cupric salts as these salts may cause rapid corrosion failure. Ferric or cupric salts may develop when hydrochloric acid comes in contact with iron or copper. |
Advantages |
a) Maintains excellent ductility during transient exposures to intermediate temperatures; |
|
b) Excellent resistance to pitting and stress-corrosion cracking |
||
c) Excellent resistance to knife-line and heat-affected zone attack |
||
Terms & Conditions |
Price Item |
FOB, CFR, CIF or as negotiation |
Payment |
T/T, LC or as negotiation |
|
Delivery Time |
30 working days after received your deposit (Normally according to the order quantity) |
|
Package |
Iron case; woven bag or as per customer’s requirement |
|
Quality Requirement |
Mill Test Certificate will be supplied with shipment, Third Part Inspection is acceptable |
|
Quality |
Test |
NTD(Ultrasonic test, Eddy Current test) |
Mechanical Test(Tension Test, Flaring Test, Flattening Test, Hardness Test, Hydraulic test) |
||
Metal Test(Metallographic Analysis, Impact Test-High/low temperature) |
||
Chemical Analysis(Photoelectric Emission Spectroscopic) |
||
Market |
Main Market |
Europe, Middle East, Southeast Asia, South America. etc |
Nickel Alloy B-3 Chemical composition:
% | Ni | Mo | Ni+Mo | Cr | Fe | W | Co | C | Mn | Si | P | S | Al | Ti | Cu | Nb | Ta | V | Zr |
min | 65.0 | 27.0 | 94.0 | 1.0 | 1.0 | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
max | - | 32.0 | 98.0 | 3.0 | 3.0 | 3.0 | 3.0 | 0.010 | 3.0 | 0.10 | 0.030 | 0.010 | 0.50 | 0.20 | 0.20 | 0.20 | 0.20 | 0.20 | 0.10 |
Features: Nickel Alloy B-3 has outstanding resistance to hydrochloric acid at all concentrations and temperatures. It also resists sulfuric, phosphoric, formic, acetic acids and other nonoxidizing media. It has excellent resistance to pitting corrosion, stress corrosion cracking, and knife line and weld heat-affected zone attack. Hastelloy B-3 has greater thermal stability than Alloy B-2
MTSCO is a leading manufacturer who is specialized in stainless steel seamless pipes , bright annealed tubes , seamless coiled tubing etc basic products . We also have duplex stainless steel tubes and pipes , nickel alloy tubes and pipes etc . MTSCO has the most advanced producing and testing equipment . We can totally satisfy your requirement .
About MTSCO:
Who MTSCO is?
MTSCO established in 2006, during many years’ development, now becomes a large and professional industrial piping system provider, serving customers from more than 100 countries and regions.
What products can MTSCO provide?
What materials can MTSCO provide?
Austenitic: 304/L/H/N,316/L/H/N/Ti,321/H,309/H,310S,347/H,317/L904L
Duplex steel: 31803,32205,32750,32760
Nickel Alloy:
UNS N10001, N10665, N10675, N06455, N06022, N10276, N06200, N06035, N06030, N06635, N10003, N06002, R30188, N06230, R30556
UNS N06600, N06601, N06617, N06625, N07718, N07750, N08800, N08810, N08811, N08825, N09925, N08926
UNS N04400, N05500
Precipitation-hardening Steels: 254SMO/S31254, 17-4PH, 17-7PH, 15-7PH
Nickel: N4/UNS N02201, N6/UNS N02200
How can MTSCO service customers?
MTSCO's ISO9001 Quality System is issued by TUV. Our full and professional inspection reports contain two parts, one is self-inspection of the requirements beyond ISO9001, which is 100% inspected by our own QC; another is 100% inspected by professional QC teams.
Thank you very much for reading this, I wonder if my presentation will help you with your current problem? Looking forward to hearing from you!
