8BWG ASTM A358 TP304L / 1.4306 ERW Steel Pipes Double Welded Annealed Surface

China 8BWG ASTM A358 TP304L / 1.4306 ERW Steel Pipes Double Welded Annealed Surface supplier
8BWG ASTM A358 TP304L / 1.4306 ERW Steel Pipes Double Welded Annealed Surface supplier 8BWG ASTM A358 TP304L / 1.4306 ERW Steel Pipes Double Welded Annealed Surface supplier 8BWG ASTM A358 TP304L / 1.4306 ERW Steel Pipes Double Welded Annealed Surface supplier 8BWG ASTM A358 TP304L / 1.4306 ERW Steel Pipes Double Welded Annealed Surface supplier

Large Image :  8BWG ASTM A358 TP304L / 1.4306 ERW Steel Pipes Double Welded Annealed Surface

Product Details:

Place of Origin: CHINA
Brand Name: MTSCO
Certification: ISO 9001 & PED & AD2000
Model Number: MTSCOSSSP50

Payment & Shipping Terms:

Minimum Order Quantity: negotiable
Price: 2400-12000USD/TON
Packaging Details: Plywood Case / Bundles
Delivery Time: 30 Days
Payment Terms: T / T ; L / C
Supply Ability: 500 Tons / Month
Contact Now
Detailed Product Description
Material: 300 Series Stainless Steel Type: Welded
NDT: Eddy Current Or Hydraulic Test Inspection: 100%
Surface: Pickling & Annealing Process: ERW , EFW Etc



8BWG ASTM A358 TP304L / 1.4306 ERW Steel Pipes Double Welded Annealed Surface







Material Grade TP304 , TP304L , TP304H , TP316 , TP316L , TP316Ti , TP309S , TP310S , TP321 , TP321H , TP347 , TP347H , etc
Outer Diameter 10.3mm-1219mm
Wall Thickness 1.24mm-59.54mm
Length Normally fixed length 6m , can as per customer’s requirement
Standard ASTM A312 ; ASTM A358 ; ASTM A789 ; ASTM A790 ect .
Process Method ERW , EFW etc







Industry & Advantage Application a) Petroleum
b) Chemical industry
c) Instrument
d) Industrial transportation
e) Mechanical structure industry
f) Need high corrision ability pipe's industry, such as offshore industry etc
Advantages a) Superior surface finish,
b) Better mechanical property
c) More precise dimension
d) Perfect inspection method and inspection equipment
Terms & Conditions Price Item FOB, CFR, CIF or as negotiation
Payment T/T, LC or as negotiation
Delivery Time 30 working days after received your deposit (Normally according to the order quantity)
Package Iron case; woven bag or as per customer’s requirement
Quality Requirement Mill Test Certificate will be supplied with shipment, Third Part Inspection is acceptable
Quality Test NTD(Ultrasonic test, Eddy Current test);
Mechanical Test(Tension Test, Flaring Test, Flattening Test, Hardness Test, Hydraulic test);
Metal Test(Metallographic Analysis, Impact Test-High/low temperature);
Chemical Analysis(Photoelectric Emission Spectroscopic)
Market Main Market Europe, Middle East, Southeast Asia, South America. etc



Birmingham Wire Gauge BWG
  Wall Thickness   Wall Thickness
BWG IN MM BWG IN MM
0 0.340 8.64 19 0.042 1.07
1 0.300 7.62 20 0.035 0.89
2 0.284 7.21 21 0.032 0.81
3 0.259 6.58 22 0.028 0.71
4 0.238 6.05 23 0.025 0.64
5 0.220 5.59 24 0.022 0.56
6 0.203 5.16 25 0.020 0.51
7 0.180 4.57 26 0.018 0.46
8 0.165 4.19 27 0.016 0.41
9 0.148 3.76 28 0.014 0.36
10 0.134 3.40 29 0.013 0.33
11 0.120 3.05 30 0.012 0.30
12 0.109 2.77 31 0.010 0.25
13 0.095 2.41 32 0.009 0.23
14 0.083 2.11 33 0.008 0.20
15 0.072 1.83 34 0.007 0.18
16 0.065 1.65 35 0.005 0.13
17 0.058 1.47 36 0.004 0.10
18 0.049 1.24



Test :



1 . X-ray , Size test , Length test

2 . Chemical Analysis ( Photoelectric Emission Spectroscopic ) etc



MTSCO has been dedicated to producing welded pipe and tube since 2003 , owning complete producing technology and abundant managing experience . And we have ISO 9001 and PED certificate , and the Third Party Inspection Certificates such as TUV , BV , Lloyd’s , SGS , etc , also can be provided according to customers’ requirements .

MTSCO is a leading manufacturer who is specialized in stainless steel seamless pipes , bright annealed tubes , seamless coiled tubing etc . In order to facilitate customers, we have welded pipes and tubes too. MTSCOMAXTECH has the most advanced producing and testing equipment . We can totally satisfy your requirement . According to standard very strictly , pipes which produced by us always have correct OD and WT tolerance .
