ASTM B574 Nickel Alloy Steel Alloy C22 / C276 Round Rod / Bar

Minimum Order Quantity : negotiable Price : 25000-100000USD/TON
Packaging Details : Plywood Case Delivery Time : 30 Days
Payment Terms : T / T ; L / C Supply Ability : 300 Tons / Month
Place of Origin: CHINA Brand Name: ERAUM
Certification: ISO 9001 & PED & AD2000 Model Number: MTSCONAT41

Detail Information

Material: Alloy C22 / C276 Type: Seamless
Technology: Cold Rolled Delivery Condition: Soft / Hard
NDT: Eddy Current Or Hydraulic Test Inspection: 100%

Product Description

ASTM B574 Nickel Alloy Steel Alloy C22 / C276 Round Rod / Bar



1. Grade :UNS N10276,UNS N10001, UNS N10665,UNS N10675, UNS N06022,N08800, N08825, N04400; etc

2 . Length : As customer's requirement

3 . Standard : ASTM B335; ASTM B574; ASTM B572; ASTM B166 etc.

4. Technology : Cold Drawn / Cold Rolled


ASTM B574 Nickel Alloy Steel Alloy C22 / C276 Round Rod / Bar



Chemical composition

% Ni Cr Mo Fe W Co C Mn Si P S V
min balance 20.0 12.5 2.0 2.5
max 22.5 14.5 6.0 3.5 2.5 0.015 0.50 0.08 0.020 0.020 0.35



Features: Alloy C-22 is a versatile Ni-Cr-Mo-W alloy with better comprehensive corrosion resistance performance than other Ni-Cr-Mo alloys, including Alloy C-276, Alloy C-4 and Alloy 625. Alloy C-22 has outstanding resistance to pitting, crevice corrosion and stress corrosion cracking. It has excellent resistance to oxidizing aqueous media including wet chlorine and mixtures containing nitric acid or oxidizing acids with chloride ions. It also offers optimum resistance to environments where reducing and oxidizing conditions are encountered in process streams. So it can be used where “upset” conditions are likely to occur or in multi-purpose plants. Alloy C-22 has exceptional resistance to a wide variety of chemical process environments, including strong oxidizers such as ferric and cupric chlorides, chlorine, hot contaminated solutions (organic and inorganic), formic and acetic acids, acetic anhydride, and seawater and brine solutions. It resists the formation of grain boundary precipitates in the weld heat-affected zone, thus making it suitable for most chemical process applications in the as-welded condition.



Applications: Chemical processing involving acetic acid, acetic anhydride and complex acid mixture; pickling operations; cellophane manufacture; chlorination systems; electro-galvanizing rolls, expansion bellows; flue gas scrubber systems; geothermal wells; HF furnace scrubbers; incineration scrubbers; nuclear fuel reprocessing; pesticide production; phosphoric acid production; heat exchangers; selective leaching systems; sulfur dioxide cooling towers; sulphonation systems; and weld overlay.
