ASTM A213 / A269 TP309S / 310S Stainless Steel Instrument Tubing Cold Rolled pipe
ASTM A213 / A269 TP309S / 310S Stainless Steel Instrument Tubing Cold Rolled pipe ASTM A213 / A269 TP309S / 310S Stainless Steel Instrument Tubing Cold Rolled pipe ASTM A213 / A269 TP309S / 310S Stainless Steel Instrument Tubing Cold Rolled pipe ASTM A213 / A269 TP309S / 310S Stainless Steel Instrument Tubing Cold Rolled pipe
Contact Now

ASTM A213 / A269 TP309S / 310S Stainless Steel Instrument Tubing Cold Rolled pipe

Minimum Order Quantity : negotiable Price : 4300-9800USD/TON
Packaging Details : Iron Case / Plywood Case Delivery Time : 30 Days
Payment Terms : T / T ; L / C Supply Ability : 300 Tons / Month
Place of Origin: CHINA Brand Name: MTSCO
Certification: MTSCOSSIT40 Model Number: ISO 9001 & PED & AD2000

Detail Information
Material: 1.4845 TP310S/TP309S Length: 5800mm
Surface: Polished Condition: Soft
Technology: Cold Drawn Test: 100% EDT
High Light:

stainless steel instrumentation tubing

,

Cold Drawn Tubing

Product Description

ASTM A213 / A269 TP309S / 310S Stainless Steel Seamless Instrument Tube With Cold Rolled







Specification :











Size		 OD : 4.76 - 25.4mm
WT : 0.71 - 2.11mm
Length : >1000Meters
4.76 * 0.71mm / 4.76 * 0.89mm / 4.76 * 1.24mm
6 * 1mm / 6 * 1.5mm
6.35 * 0.71mm / 6.35 * 0.89mm / 6.35 * 1.24mm / 6.35 * 1.65mm
7.94 * 0.71mm / 7.94 * 0.89mm / 7.94 * 1.24mm / 7.94 * 1.65mm
9.53 * 0.71mm / 9.53 * 0.89mm / 9.53 * 1.24mm / 9.43 * 1.65mm
10 * 1mm / 10 * 1.5mm
12 * 1mm / 12 * 1.5mm / 12 * 2mm
12.7 * 0.71mm / 12.7 * 0.89mm / 12.7 * 1.24mm / 12.7 * 1.65mm / 12.7 * 2.11mm
14 * 1mm / 14 * 1.5mm / 14 * 2mm
15.88 * 0.89mm / 15.88 * 1.24mm / 15.88 * 1.65mm / 15.88 * 2.11mm
16 * 1mm / 16 * 1.5mm / 16 * 2mm
19.05 * 0.89mm / 19.05 * 1.24mm / 19.05 * 1.65mm / 19.05 * 2.11mm
25.4 * 0.89mm / 25.4 * 1.24mm / 25.4 * 1.65mm / 25.4 * 2.11mm



Applications :



1 . General service industries ( petroleum , food , chemical , paper , fertilizer , fabric , aviation and nuclear )

2 . Fluid , gas and oil transport

3 . Pressure and heat transmission

4 . Construction and ornament

5 . Boiler and heat exchangers

6 . Decorative usage ( road lamp facilities , bridge handrail , expressway railing , bus stop , airport and gymnasium ) Etc



ASTM A213 / A269 TP309S / 310S Stainless Steel Instrument Tubing Cold Rolled pipe 0ASTM A213 / A269 TP309S / 310S Stainless Steel Instrument Tubing Cold Rolled pipe 1



Chemical Composition



  C(max) Si(max) P(max) S(max) Cr Ni Mo Ti
TP304/1.4301 0.080 1.00 0.045 0.030 18.0-20.0 8.0-10.5
TP304L/1.4307 0.035 1.00 0.045 0.030 18.0-20.0 8.0-12.0
TP304H/1.4948 0.04-0.10 1.00 0.045 0.030 18.0-20.0 8.0-12.0
TP316/1.4401 0.080 1.00 0.045 0.030 16.0-18.0 11.0-14.0 2.0-3.0
TP316L/1.4404 0.035 1.00 0.045 0.030 16.0-18.0 10.0-14.0 2.0-3.0
TP316Ti/1.4571 0.080 1.00 0.045 0.030 16.0-18.0 10.0-14.0 2.0-3.0 0.7>5x(C+N)
TP321/1.4541 0.080 1.00 0.045 0.030 17.0-19.0 9.0-12.0   0.7>5x(C+N)
TP317L/1.4449 0.080 1.00 0.045 0.030 18.0-20.0 11.0-14.0 3.0-4.0
TP347H/1.4912 0.04-0.10 1.00 0.045 0.030 17.0-19.0 9.0-13.0
TP309S/1.4833 0.080 1.00 0.045 0.030 22.0-24.0 12.0-15.0 0.75
TP310S/1.4845 0.080 1.00 0.045 0.030 24.0-26.0 19.0-22.0 0.75



MTSCO instrument products are made with high quality raw material. Advanced manufacture equipments and the exquisite craft, technology, characteristic of high precise size, good quality surface, stable performace, especially for the reliable durable performance under high temperature. It is widely applied in heat exchanger and condenser tubes, gas spring and lifter tubes, shock absorber tubes, automobile motocycle tubes, hydraulic tube.High pressure and super critical pressure steam boiler and so on.
