22BWG 0.71MM Wall Thickness Hydraulic Tubing , Seamless Tube ASTM A269

Minimum Order Quantity : negotiable Price : 4300-9800USD/TON
Packaging Details : Iron Case / Plywood Case Delivery Time : 30 Days
Payment Terms : T / T ; L / C Supply Ability : 300 Tons / Month
Place of Origin: CHINA Brand Name: MTSCO
Certification: ISO 9001 & PED & AD2000 Model Number: MTSCOHT06

Detail Information

Material: TP304 / 304L / 316 / 316 L / 300 Series Surface: Polished 400 #
Type: Seamless NDT: Eddy Current Or Hydraulic Test
Inspection: 100% Technology: Cold Drawn / Cold Rolled
High Light:

hydraulic tube

,

hydraulic pipe

Product Description

22BWG 0.71MM Wall Thickness Hydraulic Tubing , Seamless Tube ASTM A269





   Stainless steel seamless bright annealed tube’s final surface is polished and bright annealed . And the polished grade is includes 180 # , 320 # , 400 # , 600 # , 800 # . According to standard very strictly , tubes which produced by us always have correct OD and WT tolerance . At fluid industry , bright annealed hydraulic tubing has its own important position . Their useful life is higher than other tubing .



Applications :



1 . General service industries ( petroleum , food , chemical , paper , fertilizer , fabric , aviation and nuclear )

2 . Fluid , gas and oil transport

3 . Pressure and heat transmission

4 . Construction and ornament

5 . Boiler heat exchangers

6 . Decorative usage ( road lamp facilities , bridge handrail , expressway railing , bus stop , airport and gymnasium ) boiler , auto parts , medical equipment , building materials , food industry



Grade

304 , 304L , 304H , 310S , 316 , 316L , 316Ti , 321 , 321H , 347 , 347H , etc

Standard

ASTM A270 ; ASTM A269 ; ASTM A312 ;ASTM A249 ; EN10216-5 , ect .

Size

OD : 3.18 - 101.6mm

WT : 0.5- 20mm

Length : 1m to 12m or as per customers’ requirement

Advantage

Superior surface finish ,better mechanical property; more precise dimension; perfect inspection method and inspection equipment



22BWG 0.71MM Wall Thickness Hydraulic Tubing , Seamless Tube ASTM A269 0



Chemical Composition —— Basic Raw Materials



   ASTM/UNS

C   (max)

Si  (max)

Mn (max)

P (max)

S (max)

Cr

Ni

Mo

Ti

TP304 / S30400

0.080

1.00

2.00

0.045

0.03

18.0-20.0

8.0-10.5





TP304L / S30403

0.035

1.00

2.00

0.045

0.03

18.0-20.0

8.0-13.0





TP304H / S30409

0.04-0.10

1.00

2.00

0.045

0.03

18.0-20.0

8.0-11.0





TP316 / S31600

0.080

1.00

2.00

0.045

0.03

16.0-18.0

11.0-14.0

2.0-3.0



TP316L / S31603

0.035

1.00

2.00

0.045

0.03

16.0-18.0

10.0-14.0

2.0-3.0



TP316Ti / S31635

0.080

1.00

2.00

0.045

0.03

16.0-18.0

10.0-14.0

2.0-3.0

0.7>5x(C+N)

TP321 / S32100

0.080

1.00

2.00

0.045

0.03

17.0-19.0

9.0-12.0



0.7>5x(C+N)

TP317L / S31703

0.035

1.00

2.00

0.045

0.03

18.0-20.0

11.0-15.0

3.0-4.0



TP347H / S34709

0.04-0.10

1.00

2.00

0.045

0.03

17.0-19.0

9.0-13.0





TP309S / S30908

0.080

1.00

2.00

0.045

0.03

22.0-24.0

12.0-15.0

0.75



TP310S / S31008

0.080

1.00

2.00

0.045

0.03

24.0-26.0

19.0-22.0

0.75

























































MTSCO is a leading manufacturer who is specialized in stainless steel seamless pipes , bright annealed tubes , seamless coiled tubing etc . MTSCO has the most advanced producing and testing equipment . We can totally satisfy your requirement .
