ASME / ANSI B16.9 F51 / F53 S31803 / S32750 Duplex Steel Concentic Reducer Pipe Fitting

China ASME / ANSI B16.9 F51 / F53 S31803 / S32750 Duplex Steel Concentic Reducer Pipe Fitting supplier
ASME / ANSI B16.9 F51 / F53 S31803 / S32750 Duplex Steel Concentic Reducer Pipe Fitting supplier ASME / ANSI B16.9 F51 / F53 S31803 / S32750 Duplex Steel Concentic Reducer Pipe Fitting supplier

Large Image :  ASME / ANSI B16.9 F51 / F53 S31803 / S32750 Duplex Steel Concentic Reducer Pipe Fitting

Product Details:

Place of Origin: CHINA
Brand Name: MTSCO
Certification: ISO 9001 & PED & AD2000
Model Number: MTSCOFPF65

Payment & Shipping Terms:

Minimum Order Quantity: negotiable
Price: negotiable
Packaging Details: Plywood Case
Delivery Time: 30 Days
Payment Terms: T / T ; L / C
Supply Ability: 300 Tons / Month
Contact Now
Detailed Product Description
Material: F51 / F53 S31803 / S32750 Kinds: Concentric Or Eccentric
Type: Seamless Package: Plywood Case
PMI: 100% Standard: ASTM A403 / ASTM A182

ASME / ANSI B16.9 F51 / F53 S31803 / S32750 Duplex Steel Concentic Reducer Pipe Fitting







Material Grade

S32205 , S31803 , S32304 , S32750, F51 , F53 , 2205 , 2507 etc

Size

1/2" to 48" Sch 5S to XXS

Standard

ASTM A403, ASTM A182  etc .

Process Method

Forged / Casting



1 . Commodity: Concentric Reducer & Eccentric Reducer , Reducing Tee & Equal Tee, Elbow 45° , 90° , 180° , Cross , Cap , etc
2 . Process Method : Cold Forming
3 . Materials : Stainless Steel , Duplex Steel , etc
4 . Standards : ASME / ANSI B16.9 , B16.28 , ASTM A403 , ASTM A182, DIN 2605 , DIN 2609 , DIN 2615 , etc
5 . Size Range :
                       Seamless type: 1/2’’-48’’, DN15-DN50000
                       Welded type: 1/2’’-20’’ DN15-DN1200
6 . Tolerances : according to the specification or customer’s request and drawings
7 . Applications : oil & gas industry , chemical industry , electric power , boiler and heat exchanger , machinery , metallurgy , sanitary construction etc .





ASME / ANSI B16.9 F51 / F53 S31803 / S32750 Duplex Steel Concentic Reducer Pipe Fitting



Advantages



a) Superior surface finish

b) Better mechanical property

c) More precise dimension

d) Perfect inspection method and inspection equipment

Price Item:FOB , CFR , CIF or as negotiation

Payment:T/T, LC or as negotiation

Delivery Time :30 working days after received your deposit ( Normally according to the order quantity )

Package:Iron case ; woven bag or as per customer’s requirement

Quality Requirement:Mill Test Certificate will be supplied with shipment , Third Part Inspection is acceptable

Test:

NTD ( Ultrasonic test , Eddy Current test )

Mechanical Test ( Tension Test , Flaring Test , Flattening Test , Hardness Test , Hydraulic test )

Metal Test ( Metallographic Analysis , Impact Test - High / low temperature )

Chemical Analysis ( Photoelectric Emission Spectroscopic )





ASTM A182 / A182M Standard Chemical Composition :



Elements 304L(wt%) / F304L / S30403 304(wt%) / F340 / S30400 316L (wt%) / F316L /S31603 316 (wt%) / F316 / S31600 310 (wt%) / F310 / S31000
(C) Carbon, max 0.03 0.08 0.03 0.08 0.25
(Mn) Manganese, max 2 2 2 2 2
(P) Phosphorus, max 0.045 0.045 0.045 0.045 0.045
(S) Sulfur, max 0.03 0.03 0.03 0.03 0.03
(Si) Silicon, max 1 1 1 1 1
(Ni) Nickel 8.0 - 13.0 8.0 - 11.0 10.0 - 15.0 10.0 - 14.0 19.0 - 22.0
(Cr) Chromium 18.0 - 20.0 18.0 - 20.0 16.0 - 18.0 16.0 - 18.0 24.0 - 26.0
(Mo) Molybdenum N/A N/A 2.0 - 3.0 2.0 - 3.0 N/A
(Fe) Iron N/A N/A N/A N/A N/A
(Cu) Copper N/A N/A N/A N/A N/A
(N) Nitrogen N/A N/A N/A N/A N/A



MTSCO is a leading manufacturer who is specialized in stainless steel seamless pipes , bright annealed tubes , seamless coiled tubing etc . In order to facilitate customers , we have pipe fittings and flanges too . MTSCO has the most advanced producing and testing equipment . We can totally satisfy your requirement .
